    EPR Insulated Rubber Welding Cable Flexible Copper Conductor Chemical Resistance

    Ask Lasest Price
    Brand Name : SUNWIN
    Certification : ISO9001, ISO14001, OHSAS18001
    Price : Negotiable
    Delivery Time : 10 day
    Payment Terms : 30% deposit, the balance is settled on the delivery date
    Supply Ability : 100,000 m / month
    • Product Details
    • Company Profile

    EPR Insulated Rubber Welding Cable Flexible Copper Conductor Chemical Resistance

    EPR Insulated Rubber Welding Cable Flexible Copper Conductor Chemical Resistance


    Welding cables are generally used for connecting the electrode to the welding machine. However, welding cable can be used for a variety of other applications that require exteremely flexible and durable cables with high ampacities.


    Please contact us to get the latest price of flexible welding cable 2016.


    Flexible Power and Welding Single Core 600v


    Application: 0.6/1kv for fixed applications.

    Power: Switchboards, busbars, transformers;

    Welding: Earth and electrode leads;

    Automotive: Jumper leads, battery chargers.

    Conductor: Norminal 0.2mm stranded flexible plain copper wire to Australian AS1125.

    Insulation: Insulation rubber to Australian AS3808.

    Colors: Insulation black, red, orange.

    Packaging: 100m per roll, or bulk drum.


    Specifications - Selection Chart

    Code

    Nominal

    Area

    Conductor

    NO./DIA

    Insulation

    Thickness

    Nominal

    Overall

    Diameter

    Electrical

    Resistance

    at 20°c

    Current Rating

    2 Single Cores

    mm2mmmmmmΩ/kmAMPS
    ASWD1616511/0.21.010.11.21092
    ASWD2525784/0.21.211.80.780125
    ASWD35351120/0.21.213.10.554155
    ASWD50501568/0.21.414.90.386185
    ASWD70702240/0.21.417.00.272240
    ASWD95953040/0.21.619.30.206295
    ASWD1201203800/0.21.620.80.161345
