    Tri-rated - H05V2-K / H07V2-K / BS 6231 UL1015 CSA 22.2 Flexible PVC Cable

    Tri-rated - H05V2-K / H07V2-K / BS 6231 UL1015 CSA 22.2 Flexible PVC Cable

    APPLICATION
    High temperature, flame retardant cable designed for use in the switch control, relay and instrumentation panels of power switchgear and for purposes such as internal connectors in rectifier equipment, motor starters and controllers. Tri-rated cable is sometimes referred to as BS 6231 cable, H07V2-K or panel wire.


    CONSTRUCTION
    UL Style Number
    1015


    Conductor
    Class 5 flexible copper conductor


    CABLE STANDARDS
    BS EN 50525-2-31* BS 6231 Type CK, UL Subj.758, CSA C22.2 No. 210 (HD 21.7 S2) #LL246095,
    BS EN/IEC 60332, BS EN 60228


    The electrical and dimensional properties of this product are measured by the Technical and Quality Assurance department at the Sunwin Cables laboratory.
    Cable performance in respect of conductor resistance, construction quality (workmanship),dimensional consistency, and other parameters are verified to published standardsand approved product drawings. Conformance to RoHS (Restriction of the use ofHazardous Substances) is determined and confirmed.


    Insulation
    PVC (Polyvinyl Chloride) Type TI3


    CHARACTERISTICS
    Voltage Rating (Uo/U) UL, CSA: 600/1000V BS 6231: 600/1000V
    BS EN 50525-2-31: 300/500V, 450/750V


    Temperature Rating
    UL, CSA: +105°C BS 6231: +90°C
    Minimum: -15°C


    Minimum Bending Radius
    6 x overall diameter


    Sheath Colour
    Red Black Blue Light Blue Dark Blue Yellow Green/Yellow Grey Brown Orange White Violet Green Pink


    Note
    * BS EN 50525-2-31 covers harmonised conductor sizes up to 35mm2, cables above this size are


    generally to the specification. Where it is intended to connect cables contained within this datasheet to equipment or accessories confirmation should be obtained to ensure that they are capable of withstanding the operating temperature of the cable.

    DIMENSIONS

    Sunwin PART NO.NO. OF CORES

    NOMINAL CROSS SECTIONAL AREA
    mm²

    APPROXIMATE AWG

    NOMINAL THICKNESS OF INSULATION
    mm

    NOMINAL OVERALL DIAMETER
    mm

    NOMINAL WEIGHT
    kg/km

    A2T*000510.5210.82.711
    A2T*0007510.75190.82.8515
    A2T*001011180.8318
    A2T*001511.5160.83.323
    A2T*002512.5140.83.7535
    A2T*004014120.84.3548
    A2T*006016100.84.8569
    A2T*010110816.3117
    A2T*016116618.1191
    A2T*02512541.29.4281
    A2T*03513521.210.9389
    A2T*05015011.413.1560
    A2T*0701702/01.415.1774
    A2T*0951953/01.616.1991
    A2T*12011204/01.617.91231
    A2T*1501150250 MCM1.820.21534
    A2T*1851185350 MCM222.851878
    A2T*2401240450 MCM2.224.42381


    * Sunwin Part No. shown above designate the sheath colour (*). For each colour substitute * for a colour code as listed below. e.g. A2TRD0040 = 4mm2 Red


    Colour Codes

    COLOURBlackGreenBlueLight BlueDark BlueGreyGreen/ YellowOrangeRedPinkYellowVioletBrownWhite
    CODEBKGNBLLTBLDKBLGRGYORRDPKYWVIBRWH


    CONDUCTORS
    Class 5 Flexible Copper Conductors for Single Core and Multi-Core Cables

    NOMINAL CROSS
    SECTIONAL AREA
    mm²

    MAXIMUM DIAMETER OF
    WIRES IN CONDUCTOR
    mm

    MAXIMUM RESISTANCE OF
    CONDUCTOR AT 20ºC

    Plain Wires
    ohms/km

    0.50.2139
    0.750.2126
    10.2119.5
    1.50.2613.3
    2.50.267.98
    40.314.95
    60.313.3
    100.411.91
    160.411.21
    250.410.78
    350.410.554
    500.410.386
    700.510.272
    950.510.206
    1200.510.161
    1500.510.129
    1850.510.106
    2400.510.0801


    The above table is in accordance with BS EN 60228 (previously BS 6360)


    ELECTRICAL CHARACTERISTICS
    Current Carrying Capacity and Voltage Drop

    NOMINAL CROSS SECTIONAL AREA
    mm²

    CURRENT RATING (PEAK)
    Amps

    VOLTAGE DROP
    mV/A/m

    0.51146
    0.751431
    11722
    1.52115
    2.5309.1
    4415.7
    6533.8
    10752.2
    161001.4
    251360.89
    351670.64
    502040.45
    702590.32
    953210.24
    1203740.19
    1504290.16
    1854960.13
    2405950.1


    Current ratings are based on a conductor operating temperature of 90°C and an ambient air temperature of 45°C and assumes single cable isolated in free air.



    DE-RATING FACTORS

    AMBIENT TEMPERATURE45°C50°C55°C60°C65°C70°C75°C
    DE-RATING FACTOR1.000.970.900.820.730.630.52


    Where cables are to be grouped, the following factors should be applied

    NO. OF CABLES IN GROUP2345678
    DE-RATING FACTOR0.800.700.650.600.560.530.50



    The information contained within this datasheet is for guidance only and is subject to change without notice or liability. All the information is provided in good faith and is believed to be correct at the time of publication. When selecting cable accessories, please note that actual cable dimensions may vary due to manufacturing tolerances.
