BS 6724 CopperLow Smoke Zero Halogen Cable Multi Core SWA LSZH BASEC 0.6kV / 1kV

    Buy cheap BS 6724 CopperLow Smoke Zero Halogen Cable Multi Core SWA LSZH BASEC 0.6kV / 1kV from wholesalers

    Buy cheap BS 6724 CopperLow Smoke Zero Halogen Cable Multi Core SWA LSZH BASEC 0.6kV / 1kV from wholesalers
    • Buy cheap BS 6724 CopperLow Smoke Zero Halogen Cable Multi Core SWA LSZH BASEC 0.6kV / 1kV from wholesalers

    BS 6724 CopperLow Smoke Zero Halogen Cable Multi Core SWA LSZH BASEC 0.6kV / 1kV

    Ask Lasest Price
    Brand Name : SUNWIN
    Certification : ISO9001, ISO14001, OHSAS18001
    Price : Negotiable
    Delivery Time : 10 day
    Payment Terms : 30% deposit, the balance is settled on the delivery date
    Supply Ability : 100,000 m / month
    • Product Details
    • Company Profile

    BS 6724 CopperLow Smoke Zero Halogen Cable Multi Core SWA LSZH BASEC 0.6kV / 1kV

    BS 6724 CopperLow Smoke Zero Halogen Cable Multi Core SWA LSZH BASEC 0.6kV / 1kV


    APPLICATION

    Multi-core LSZH cable with steel wire armour (SWA). Power and auxiliary control cables for use in power networks, underground, outdoor and indoor applications and for use in cable ducting. For installation where fire, smoke emission and toxic fumes create a potential threat to life and equipment.


    CONSTRUCTION
    Conductor

    Class 2 stranded copper conductor according to BS EN 60228
    (previously BS 6360)


    Insulation
    XLPE (Cross-Linked Polyethylene) Type GP8 according to BS 7655


    Bedding
    LSZH (Low Smoke Zero Halogen) Type LTS1 according to BS 7655


    Armour

    SWA (Steel Wire Armour)


    Sheath

    LSZH (Low Smoke Zero Halogen) Type LTS1 according to
    BS 7655


    STANDARDS

    BS 6724, BS EN/IEC 60502-1, BS EN/IEC 60754-1 and 2 BS EN 50267-2-1 and 2, BS EN/IEC 61034-1, BS EN/IEC 60332-1-2, BS EN/IEC 60332-3-24 Cat C


    We supply LPCB Certified products
    The electrical and dimensional properties of this product are measured by the Technical and Quality Assurance department at the Cables laboratory. Cable performance in respect of conductor resistance, construction quality (workmanship), dimensional consistency, and other parameters are verified to published standards and approved product drawings. Conformance to RoHS (Restriction of the use of Hazardous Substances) is determined and confirmed


    CHARACTERISTICS
    Voltage Rating

    600/1000V


    Temperature Rating
    Fixed installation: -20°C to +90°C


    Minimum Bending Radius
    1.5mm2 to 16mm2 - Fixed: 6 x overall diameter
    25mm2 and above - Fixed: 8 x overall diameter


    Core Identification
    2 core: Brown Blue
    3 core: Brown Black Grey
    4 core: Brown Blue Black Grey
    5 core: Green/Yellow Brown Blue Black Grey


    Alternative Core Identification:
    White cores with Black numbers


    Sheath Colour
    Black
