Copper Core Low Smoke Zero Halogen Wire Four Core XLPE Insulated Ls0h Cable

    Buy cheap Copper Core Low Smoke Zero Halogen Wire Four Core XLPE Insulated Ls0h Cable from wholesalers

    Buy cheap Copper Core Low Smoke Zero Halogen Wire Four Core XLPE Insulated Ls0h Cable from wholesalers
    • Buy cheap Copper Core Low Smoke Zero Halogen Wire Four Core XLPE Insulated Ls0h Cable from wholesalers

    Copper Core Low Smoke Zero Halogen Wire Four Core XLPE Insulated Ls0h Cable

    Ask Lasest Price
    Brand Name : SUNWIN
    Certification : ISO9001, ISO14001, OHSAS18001
    Price : Negotiable
    Delivery Time : 10 day
    Payment Terms : 30% deposit, the balance is settled on the delivery date
    Supply Ability : 100,000 m / month
    • Product Details
    • Company Profile

    Copper Core Low Smoke Zero Halogen Wire Four Core XLPE Insulated Ls0h Cable

    Copper Core Low Smoke Zero Halogen Wire Four Core XLPE Insulated Ls0h Cable


    APPLICATION


    BS 5308 cables are designed to carry communication and control signals in a variety of installation types including those found in the petrochemical industry. The signals can be of analogue, data or voice types and from a variety of transducers such as pressure, proximity or microphone. Part 1 Type 2 cables are designed where a greater degree of mechanical protection is required or where there is direct burial at a
    suitable depth. Collectively and individually screened pairs are available within the range.


    CONSTRUCTION
    Conductor

    Class 1 solid copper conductor according to BS EN 60228 (previously BS 6360)
    Class 2 stranded copper conductor according to BS EN 60228 (previously BS 6360)
    Class 5 flexible copper conductor according to BS EN 60228 (previously BS 6360)


    Insulation

    MICA Tape + XLPE (Cross-Linked Polyethylene)


    Binder Tape
    PET (Polyester Tape)


    Screen
    AL/PET (Aluminium/Polyester Tape)


    Drain Wire
    Tinned copper


    Inner Sheath
    LSZH (Low Smoke Zero Halogen) Type LTS3 according to BS 7655


    Armour
    Galvanized steel wires


    Outer Sheath
    LSZH (Low Smoke Zero Halogen) Type LTS3 according to BS 7655


    STANDARDS

    BS/PAS 5308, BS EN 60228, BS 6234, BS EN 50363, BS EN/IEC 60331-21, BS EN/IEC 60332-3-24, BS EN/IEC 60332-1, BS EN/IEC 61034-2,
    BS EN/IEC 60754-1 and 2, BS EN/IEC 60332-3-22


    We supply LPCB Certified products
    The electrical and dimensional properties of this product are measured by the Technical and Quality Assurance department at the Cables laboratory. Cable performance in respect of conductor resistance, construction quality (workmanship), dimensional consistency, and other parameters are verified to published standards and approved product drawings. Conformance to RoHS (Restriction of the use of Hazardous Substances) is determined and confirmed


    Voltage Rating (Uo/U)

    300/500V


    Temperature Rating
    +90°C


    Sheath Colour
    Red Black


    LSZH cable selection

    There have been many developments in relation to LSZH cable standards and legislation since the Kings Cross Station fire of November 1987 which resulted in 31 fatalities. Findings from the official investigation outlined that the majority of these deaths were as a result of toxic fumes, pointing to the vast quantities of PVC present in the building, much of which was in PVC cables. PVC cables were subsequently banned by London Underground.

    As a leading rail & metro cable supplier, Eland Cables is well-positioned to understand the implications involved when selecting an LSZH cable for use in any other industry. Please contact our technical team to discuss your specific requirements and our comprehensive range of LSZH cables for all applications, including building & construction, oil & gas, and marine & offshore.

    Quality Copper Core Low Smoke Zero Halogen Wire Four Core XLPE Insulated Ls0h Cable for sale
